Scott Patron 920

BRAND

Scott

FAMIGLIA MODELLO

Patron

ANNO

2025

COLORE

Granite Black, Martin Green

TELAIO

Alloy Frame
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
Bosch Smart System / UDH Interface / 12x148mm with 55mm Chainline
Bosch PowerMore Ready

MATERIALE TELAIO

Alluminio

ESCURSIONE

Front: 150mm / Rear: 150mm

FORCELLA

RockShox Psylo Silver RC Air / E-Bike / Comp & Reb Adj. / QR Axle 15x110mm axle
44mm offset / tapered steerer / 150mm travel

AMMORTIZZATORE POSTERIORE

X-Fusion NUDE 5 RLX Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Reb. Adj.
Travel 150-100-Lockout / T185X55mm

COMANDO REMOTO

SCOTT TracLoc 2 Technology
Suspension & Dropper Remote
3 modes

MOTORE

Bosch Performance CX
EU: 25kmh / INT: 20mph

BATTERIA

PowerTube 800Wh

DISPLAY

Bosch System Controller
Mini Remote & Intuvia 100

CARICATORE

4A Charger

DERAGLIATORE POSTERIORE

Shimano Deore RD-M6100 SGS
Shadow Plus / 12 Speed

LEVE DEL CAMBIO

Shimano Deore SL-M6100-IR / Rapidfire Plus

GUARNITURA

FSA Alloy

GUIDACATENA

e*thirteen / e*spec Slider

CORONA

FSA 12 Speed 34T chainring

CATENA

Shimano CN-M6100

PACCO PIGNONI

Shimano CS-M6100 / 10-51

FRENI

Shimano MT520 4 Piston Disc

ROTORI

Front: SM-RT64 CL 220mm / Rear: SM-RT64 CL 203mm

MANUBRIO

Syncros Hixon 2.0 Alloy 6061
Size S & M 15mm rise / Size L & XL 25mm rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips

ATTACCO MANUBRIO

Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8″

REGGISELLA

Syncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm

SELLA

Syncros Tofino-E 2.5 Regular

SERIE STERZO

Syncros – Acros Angle adjust & Cable Routing HS System / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB

MOZZO ANTERIORE

Formula CL-811 / 15x110mm

MOZZO POSTERIORE

Formula ECT-148M / Boost 148x12mm

RAGGI

Stainless Black

CERCHIO

Syncros MD30 / 32H / 30mm / Pin Joint
Tubeless ready

GOMMA ANTERIORE

Maxxis Forekaster 29×2.6″
120TPI Foldable Bead
EXO / TR Tubeless ready
3C Maxx Terra

GOMMA POSTERIORE

Maxxis Forekaster 29×2.6″
120TPI Foldable Bead
EXO / TR Tubeless ready
3C Maxx Terra

LUCI

Syncros integrated rear fender light
Front Light Cable pre-installed

PESO

25.8 Kg (with tubes)

CODICE ARTICOLO

423363
